PRODUCT

LWDM DEMUX

cable fibers
LAN-Wavelength Division Multiplexing optical demultiplexer

  • Enablence’s LAN-Wavelength Division Multiplexing (LWDM) optical demultiplexer (DEMUX) combines a sophisticated arrayed waveguide grating (AWG) design with a quality fabrication. The DEMUX operates on the LWDM grid, extracting the wavelengths from a single input into separate channels for detection by a photodiode. The AWG design provides extremely low loss, wide passbands, and high flatness. The LWDM DEMUX is qualified for 85/85 Damp Heat and other industry standard reliability requirements.

  • We currently offer designs with outputs on a 250 µm pitch, with 2 different wavelength orders. Other layouts can be considered upon demand.

  • The LWDM DEMUX are available in wafer form, bar form, polished chip, and assembled chip.

LWDM MUX

network around globe

  • Enablence LAN Wavelength Division Multiplexing (LWDM) optical multiplexer (MUX) is available using our proprietary Vortex design. The MUXes combine the Vortex design with a quality fabrication. The Vortex design provides low loss, wide passbands, and high flatness. The PLC is ruggedized against Damp Heat (85/85) and other industry standard reliability requirements.

  • We currently offer a design with inputs and output on opposite sides. The inputs are on a 500 µm pitch (LR4) or 750 um pitch (LR8). However, other layouts can be considered upon demand. The chips are used typically for 5G and datacom applications.

  • The LWDM MUX are available in wafer form, bar form, polished chip, and assembled chip.
